Điều Hòa OHM - OCA-H300BC-A200

OCA-H300BC-A200

83.611.700₫

Số lượng:

Model		OCA-H300BC-A200
Type of mounting		Lateral mounting
Cooling capacity　※1		250/300W
Rated voltage		Single phase 200VAC　50/60Hz
Current consumption　※2	Rated	1.4/1.3A
Current consumption　※2	Max.	1.6/1.5Ａ
Starting current		3.7/3.6A
Power consumption　※2	Rated	250/260W
Power consumption　※2	Max.	280/290W
Compressor motor output		100W
Working temperature ※3		＋20 to＋50℃
Working humidity		Not exceeding 85%RH, free from condensation
Noise (Characteristic A)		65dB
Setting temperature range ※3		＋30 to ＋45℃　(Initial setting: +35℃)
Display		Internal temperature, Alarm code/Operation lamp, Alarm lamp
Function		Off-temperature alarm Detection of abnormal heat dissipation Detection of temperature sensor disconnection Maintenance reminder Forced cooling operation for inspection
External output		Alarm output 1c 240V 1.5A×2(COMMON)
Vibration resistance		Vibration frequency: 10 to 55Hz Amplitude: 0.15mm Sweep cycle 10 times
Protective category		Internal circuit : IP54 equivalent
Applicable standards	EMC Directive	EN61000-6-2 and EN61000-6-4 compliant
	LV Directive	EN60335-1, EN60335-2-40, EN62233
	Environment	RoHS
Refrigerant		R1234yf (110g)
GWP		＜1
Body color		Powder coating/ N8/N4 equivalent
Dimensions(in mm)		W300×H500×D150
Weight		16.0kg

*1. Nominal values when temperatures both inside and outside the enclosure is 35℃.

*2. Values at 35℃ temperature both inside and outside are indicated in “Rated” and values at 50℃ outside and 35℃ inside are indicated in “Max.”

*3. These products should not be used outside the temperature range.

*4. Drain pipe is excluded.

*5. By IPCC 5th Report 2013

●Please contact us for other supply voltages than 200VAC.
●Supply voltage should be within the fluctuation range of 10% from the rated voltage.
